TRIADEO^® Smart Hydrogen Sulfide Countermeasures for Installation in a Glove Box

What is TRIADEO^® Smart?

TRIADEO® Smart is a hydrogen sulfide (_H₂S) control device installed inside the glove box. By removing hydrogen sulfide and other harmful gases, it improves the working environment and enhances safety.
As a safety measure for glove boxes, it supports safety management during research and development of sulfide-based solid electrolytes and all-solid-state battery-related work.

Features

Simply install it inside the glove compartment to easily remove hydrogen sulfide (_H₂S elimination) or organic solvents.
As a compact hydrogen sulfide countermeasure device, it can be installed in existing glove boxes in a space-saving manner.
This system allows for easy implementation of enhanced safety measures for glove boxes without requiring any special piping work.
In environments where low concentrations of hydrogen sulfide are generated, this product contributes to ensuring worker safety and improving the working environment.

Usage

Applications for _H₂S control in the research and development process of sulfide-based solid electrolytes.
Measures to remove harmful gases during electrode material evaluation
As a safety measure for all-solid-state batteries, we are addressing the issue of hydrogen sulfide generated during the assembly and disassembly process.
Used as safety management equipment during battery stress testing.
It can be used as a hydrogen sulfide removal device in glove box environments where low concentrations of H₂S are generated.
Safety measures for research and development environments involving lithium-ion batteries, all-solid-state batteries, and next-generation rechargeable batteries.
Future applications are expected to include general use in research equipment utilizing sulfide-based materials.

Standard Specification

Processing air volume	4.2m³/h
Weight	Approximately 1.6 kg
Size	W86mm×D86mm×H290mm
Power supply	4.5W (5V, 0.9A) 100V → 5V AC adapter included
Filter	Intake side, exhaust side
Remarks	Type A: For hydrogen sulfide Type B: For organic solvents
